Aluminum Standing Docks / on wheels

Depending on your landscape, The Lighthouse Docks will create the perfect dock setup for your needs, either standing or on wheels. The lightweight of our aluminum dock will facilitate the installation and removal every season. We offer either Natural West Cedar panels, PVC or SunWalk panels (reinforced polypropylene). We have many accessories that can complete your dream setup. We can also paint the structure of your docks!!
Available
Features
  • Modular dock system with infinite configuration
  • Allowing you to easily get to your boat lift or simply relax
  • Handrail and many accessories available for increased security
  • Available in the following widths: 4', 5', 6' and 8'
  • Available in three lengths: 10', 15' and 20'
  • Also manufactured in square, octagonal and semi-octagonal format
  • Possibility to customize
  • Ideal for shallow water
Characteristics
  • Lightweight aluminum dock structure
  • Removable decking in red cedar panels, PVC or "Sunwalk" (reinforced polypropylene) panels
  • 6''x8'' bottom plates or wheels (optional)
  • 6' galvanized posts with black rubber caps and junction plates.
Advantages
  • Aestheticism of the product
  • Very stable and lightweight aluminum dock
  • Safe
  • CWB certification
  • Easy to install
  • Very affordable

Technical sheet

Dimension Structure Weight Available Decking Weight Red Cedar Panel Weight PVC Panel Weight Sunwalk Panel Included with Structure & Decking
28"x10' 42 lbs Red Cedar or PVC 28 lbs x2 40 lbs x2 N/A
  • 2x6" galvanized post
  • 2x bottom plates
  • 2x vinyl caps & joint plates
28"x15' 70 lbs Red Cedar or PVC 28 lbs x3 40 lbs x3 N/A
  • 2x6" galvanized post
  • 2x bottom plates
  • 2x vinyl caps & joint plates
4'x10' 61 lbs Red Cedar or PVC or Sunwalk* 47 lbs x2 67 lbs x2 30 lbs
  • 2x6" galvanized post
  • 2x bottom plates
  • 2x vinyl caps & joint plates
4'x15' 87 lbs Red Cedar or PVC or Sunwalk* 47 lbs x3 67 lbs x3 45 lbs
  • 2x6" galvanized post
  • 2x bottom plates
  • 2x vinyl caps & joint plates
4'x20' 117 lbs Red Cedar or PVC or Sunwalk* 47 lbs x4 67 lbs x4 60 lbs
  • 4x6" galvanized post
  • 4x bottom plates
  • 4x vinyl caps & joint plates
5'x10' 65 lbs Red Cedar or PVC or Sunwalk* 58 lbs x2 84 lbs x2 36 lbs
  • 2x6" galvanized post
  • 2x bottom plates
  • 2x vinyl caps & joint plates
5'x15' 93 lbs Red Cedar or PVC or Sunwalk* 58 lbs x3 84 lbs x3 54 lbs
  • 2x6" galvanized post
  • 2x bottom plates
  • 2x vinyl caps & joint plates
5'x20' 124 lbs Red Cedar or PVC or Sunwalk* 58 lbs x4 84 lbs x4 72 lbs
  • 4x6" galvanized post
  • 4x bottom plates
  • 4x vinyl caps & joint plates
6'x10' 69 lbs Red Cedar or PVC or Sunwalk* 72 lbs x2 51 lbs x4 45 lbs
  • 2x6" galvanized post
  • 2x bottom plates
  • 2x vinyl caps & joint plates
6'x15' 103 lbs Red Cedar or PVC or Sunwalk* 72 lbs x3 51 lbs x6 67 lbs
  • 2x6" galvanized post
  • 2x bottom plates
  • 2x vinyl caps & joint plates
6'x20' 136 lbs Red Cedar or PVC or Sunwalk* 72 lbs x4 51 lbs x8 89 lbs
  • 4x6" galvanized post
  • 4x bottom plates
  • 4x vinyl caps & joint plates
8'x10' 94 lbs Red Cedar or PVC or Sunwalk* 47 lbs x4 67 lbs x4 58 lbs
  • 2x6" galvanized post
  • 2x bottom plates
  • 2x vinyl caps & joint plates
8'x15' 122 lbs Red Cedar or PVC or Sunwalk* 47 lbs x6 67 lbs x6 87 lbs
  • 3x6" galvanized post
  • 3x bottom plates
  • 2x vinyl caps & joint plates
8'x20'157 lbsRed Cedar or PVC or Sunwalk*47 lbs x867 lbs x8115 lbs
  • 6x6" galvanized post
  • 6x bottom plates
  • 4x vinyl caps & joint plates

Square 10'x10'140 lbsRed Cedar or PVC2x 86 lbs & 1x 74 lbs2x 121 lbs & 2x 105 lbsN/A
  • 5x6" galvanized posts
  • 5x bottom plates
  • 4x vinyl caps & platform bracket
Octagon 10' 120 lbs Red Cedar or PVC 2x 46 lbs & 2x 47 lbs 2x 66 lbs & 2x 68 lbs N/A
  • 4x6" galvanized posts
  • 4x bottom plates
  • 4x vinyl caps & platform bracket
Octagon 3/4 129 lbs Red Cedar or PVC 2x 71 lbs & 1x 70 lbs 2x 103 lbs & 1x 101 lbs N/A
  • 4x6" galvanized posts
  • 4x bottom plates
  • 4x vinyl caps & platform bracket
Square 12'x12' - 2-pieces 202 lbs Red Cedar or PVC 2x 85 lbs & 2x 80 lbs 2x 119 lbs & 2x 110 lbs N/A
  • 7x6" galvanized posts
  • 7x bottom plates
  • 6x vinyl caps & platform bracket
Octagon 12' - 2-pieces 165 lbs Red Cedar or PVC 2x 71 lbs & 2x 70 lbs 2x 103 lbs & 2x 101 lbs N/A
  • 6x6" galvanized posts
  • 6x bottom plates
  • 6x vinyl caps & platform bracket

* Our aluminum structures are 4” wider when we install Sunwalk panels (reinforced polyurethane).
