Aluminum Gangway

Pour compléter l’aménagement de votre quai, Les Quais du Phare fabriquent des passerelles et plates-formes flottantes. Leur structure légère en aluminium vous permettra un déplacement facile et une protection contre la rouille et la corrosion. Afin de personnaliser l’apparence de votre passerelle ou plate-forme, nous vous proposons un vaste choix d’accessoires et des recouvrements de quai en cèdre rouge, en cèdre rouge teint Teck ou en polypropylène renforcé.
Available
Features
  • Facilitates shore access to the standing dock or floating dock
  • Adapts to river bank imbalances
  • Extends your dock at a lower cost
  • Handrail available for added security on your dock or gangway
  • Available in the following widths: 28'', 3', 4' and 5'
  • Two lengths available: 10' and 15'
  • Aluminum gangway also available custom made .
Characteristics
  • Lightweight aluminum gangway structure
  • Removable decking in red cedar, PVC or "Sunwalk" (reinforced polypropylene)
  • Connecting hinges for docks on piles or floating docks.
Advantages
  • Aestheticism of the product
  • Very stable and lightweight aluminum dock
  • Safe
  • CWB certification
  • Easy to install
  • Very affordable
Product number P2810 (pour 28’’ x 10’)

Technical sheet

Dimension Structure Weight Available Decking Weight Red Cedar Panel Weight PVC Panel Weight Sunwalk Panel Included with Structure & Decking
28"x10' 40 lbs
  • Red Cedar
  • PVC
28 lbs x2 40 lbs x2 N/A Gangway Bracket
28"x15' 70 lbs
  • Red Cedar
  • PVC
28 lbs x3 40 lbs x3 N/A Gangway Bracket
3'x10' 55 lbs
  • Red Cedar
  • PVC
  • Sunwalk*
35 lbs x2 50 lbs x2 23 lbs Gangway Bracket
3'x15' 78 lbs
  • Red Cedar
  • PVC
  • Sunwalk*
35 lbs x3 50 lbs x3 34 lbs Gangway Bracket
4'x10' 65 lbs
  • Red Cedar
  • PVC
  • Sunwalk*
47 lbs x2 67 lbs x2 30 lbs Gangway Bracket
4'x15' 91 lbs
  • Red Cedar
  • PVC
  • Sunwalk*
47 lbs x3 67 lbs x3 45 lbs Gangway Bracket
5'x10' 70 lbs
  • Red Cedar
  • PVC
  • Sunwalk*
58 lbs x2 84 lbs x2 36 lbs Gangway Bracket
5'x15' 98 lbs
  • Red Cedar
  • PVC
  • Sunwalk*
58 lbs x3 84 lbs x3 54 lbs Gangway Bracket
6'x10' 75 lbs
  • Red Cedar
  • PVC
  • Sunwalk*
72 lbs x2 51 lbs x4 45 lbs Gangway Bracket
6'x15' 105 lbs
  • Red Cedar
  • PVC
  • Sunwalk*
72 lbs x3 51 lbs x6 67 lbs Gangway Bracket

*Our aluminum structures are 4" wider when we install Sunwalk panels (reinforced polyurethane).
